Quality Control with Flipper Conveyor

<< LM-CU/2300 LM-SR/3500 >>
MATTRESS LM-CON/2200 Quality Control with Flipper Conveyor

This conveyor is designed to allow operators to carry out quality control inspections and mattress cleaning more easily before the product is packaged

Mattresses automatically stay centered on the quality control conveyor. The operator can press a button to lift centered mattresses over the conveyor. They can then conduct a quality control of all sides by rotating the mattresses

Afterwards, by pressing reversing button, it turns the mattress over 180 degrees. Once both sides of a mattress have been checked, the mattress is then automatically transferred to the packaging machine

With its flexible and ergonomic working principle, quality control process is completed without damaging the mattress through turning and rotating

APPLICATION AREA

Mattress Industry

Foam Lamination System

MATERIALS

Mattress

Foam

STANDARD

Flipping Unit

Pneumatic Mattress Lift System

PVC Belt Conveyor
